Fin density (FPI: fins per inch): 8–12 FPI
8–9 FPI: Wide gap, anti-dust clogging for field welding
10–12 FPI: Higher heat exchange area for high-current machines
Fin thickness: 0.08–0.15mm adjustable
Liquid flow path: Single pass / double pass parallel flow (reduce water pressure drop)
Design cooling capacity: Custom calculated based on welding current (1kW–6kW cooling load)
Working pressure: 0.3–0.6MPa (standard welding water loop pressure)
Operating temperature range: -10°C ~ 70°C (match coolant with antifreeze)
Fin surface treatment: Bare aluminum / black anti-oxidation coating / hydrophilic coating
Add-on: Flow sensor mounting holes, drain port, overflow port, customized water manifold, quick-disconnect torch fittings
OEM: Custom logo stamped on side frame
