G-coil is the most recommended retail retrofit upgrade.
Pros: 3-sided surrounding airflow, compact bent structure fits square cassette inner cavity perfectly, better heat exchange & humidity control than A-coil, same mounting footprint for drop-in replacement without cabinet modification, lower air resistance reduces fan noise
Fit scenario: Supermarkets, clothing stores, cafes, humid coastal cities, high foot traffic retail with heavy latent load.
Step-by-Step Replacement Workflow for Retail Cassette AC
Preparation
Shut off power supply to cassette unit; cover display shelves, lighting and floor goods to avoid water or dust contamination. Prepare matched G-coil, expansion valve, insulation tape, cleaning blower and drain pipe accessories.
Disassembly
Remove air outlet panels, suction grille; drain residual refrigerant (recover for recycling), disconnect copper tubing and drain hose; take out old failed A-coil.
New coil installation
Position G-coil into the cassette internal frame, align mounting brackets; braze refrigerant pipelines, connect drain hose tightly; add thermal insulation on all copper joints to prevent sweating.
Testing & commissioning
Vacuum refrigerant circuit, recharge matched refrigerant; power on test cooling operation, check drain speed, air outlet temperature and noise level; confirm no water leakage or abnormal frost on coil surface.
Site cleanup
Wipe dust, restore ceiling panels, remove protective covers over retail goods.
Key Selection Specifications for Replacement Coils
Fin density
Humid tropical/coastal retail areas: 10–11 FPI hydrophilic aluminum fins (enhance dehumidification)
Inland dry climate shops: 12–13 FPI fins (higher sensible cooling efficiency)
Tube material: Standard 3/8” inner grooved copper tube for high heat transfer
Tonnage matching: Strictly select coil capacity same as original cassette (2HP / 3HP / 5HP mainstream retail models)
Surface coating: Hydrophilic anti-corrosion coating to resist mold growth under long-hour humid operation
