Multi-tier continuous conveyor mesh belt dryers—used for dehydrating vegetables, pet treats, chemical briquettes, biomass pellets, and herbal medicines—require high-output, modular steam heating coils capable of continuous 24/7 industrial duty.
At CSTHEATEXCHANGER, we engineer Heavy-Duty Steam Heating Coils for Continuous Mesh Belt Dryers. Custom-dimensioned to fit modular heating chambers, our steam coils deliver rapid air temperature rise, uniform cross-belt thermal distribution, and rugged resistance to moisture and particulate fouling.
Multi-Zone Staged Temperature Sizing: Modular coil blocks allow independent temperature setpoints across conveyor drying stages, optimizing moisture evaporation curves.
Uniform Cross-Belt Air Distribution (±1.0∘C): Balanced multi-pass steam circuiting ensures identical drying rates across belt widths up to 3.5 meters.
Heavy-Gauge Steam & Pressure Durability: Seamless SA106B boiler steel or 304/316L stainless steel tubes withstand steam pressures up to 1.6 MPa and thermal expansion cycles.
Anti-Clogging Wide Fin Pitch (3 to 6 FPI): Extruded bimetallic aluminum fins prevent airborne product dust and fibers from bridging between fins.
Parameter | CSTHEATEXCHANGER Belt Dryer Steam Coil Specs |
|---|---|
Belt Dryer Duty | Single-Pass & Multi-Tier Conveyor Mesh Belt Dryers |
Steam Operating Pressure | Saturated Steam 0.3 MPa to 1.6 MPa (3 bar – 16 bar) |
Delivered Chamber Temp | 60°C – 180°C (Multi-Zone Staged Temperature Control) |
Tube Metallurgy | Seamless Carbon Steel (SA106B/20G), SS304, SS316L |
Fin Geometry | Extruded Bimetal Al, Solid Spiral Welded Steel (3–8 FPI) |
Ensure uniform continuous drying throughput. Contact CSTHEATEXCHANGER today for belt dryer steam coil engineering calculations and layout drawings.
