Before carbonated water enters filling lines or blending tanks, it must be chilled to a controlled low temperature—typically 0 to 4°C. Lower temperatures improve CO₂ solubility, helping the carbonated water maintain the desired carbonation level during production and bottling.
A plate heat exchanger provides the fast, hygienic, and energy-efficient cooling required in this process.
How a Plate Heat Exchanger Works in Carbonated Water Chillers
A PHE consists of multiple thin, corrugated stainless-steel plates that create alternating flow channels for the process fluid (carbonated water) and the cooling medium (glycol or chilled water).
Process Flow:
Carbonated water enters the PHE at elevated temperature.
Chilled glycol or chilled water flows through the adjacent channels in counterflow direction.
Heat transfers rapidly through the thin stainless-steel plates due to high turbulence and surface area.
Carbonated water exits the PHE at a precisely chilled temperature—ready for filling or further mixing.
The high turbulence inside the channels ensures excellent heat-transfer efficiency without damaging the carbonation level.
Advantages of Using a Plate Heat Exchanger for Carbonated Water Cooling
1. Fast and Efficient Cooling
The corrugated plate design increases turbulence, allowing rapid temperature reduction even with compact equipment.
2. Hygienic Stainless-Steel Construction
Food-grade stainless steel (usually SS304 or SS316) ensures sanitary operation and compliance with beverage industry standards.
3. Excellent CO₂ Retention
The gentle, uniform cooling prevents CO₂ loss, maintaining the correct carbonation level.
4. Compact and Space-Saving
Compared to shell-and-tube exchangers, PHE units deliver higher performance with a smaller footprint—ideal for beverage factories and bottling lines.
5. Easy to Clean and Maintain
Most beverage-grade PHEs support:
CIP cleaning (Clean-in-Place)
Easy disassembly for inspection
Gasket replacement without major downtime
6. Low Energy Consumption
The counterflow design maximizes heat-transfer efficiency, reducing glycol chiller load and lowering operating costs.
Typical Applications in Beverage and Carbonation Plants
Plate heat exchangers are widely used in:
Carbonated water chilling
Soft drink production
Sparkling beverage mixing systems
CO₂ injection cooling stage
Syrup cooling and blending
Pre-cooling for bottling lines
Brewery carbonation systems
Any application requiring precise, sanitary, and rapid cooling of carbonated liquids can benefit from a PHE.
Design Considerations for a Carbonated Water Plate Heat Exchanger
When selecting a PHE for a carbonation system, engineers consider:
Flow rate of carbonated water
Inlet and outlet temperature requirements
CO₂ concentration levels
Cooling medium (glycol/brine/chilled water)
Pressure rating and allowable pressure drop
Plate material (SS316 recommended for chloride-rich environments)
Gasket type (EPDM, NBR, or high-temperature variants)
Proper sizing ensures stable carbonation, efficient cooling, and long-term reliability.
