Rectangular Air to Air Heat Exchanger

The rectangular air-to-air heat exchanger is a widely used device in HVAC systems. Its main function is to transfer heat between two different air streams to achieve energy recovery and reuse, thereby improving the energy efficiency of the system.

In the ventilation systems of some large commercial buildings, fresh outdoor air and indoor exhaust air are exchanged for heat through rectangular air-to-air heat exchangers. In the cold season, the warm indoor exhaust air can preheat the incoming fresh cold air, reducing the energy consumption required to heat the fresh air; while in the hot season, the cold indoor exhaust air can pre-cool the incoming hot air, reducing the energy consumption required for cooling.

The rectangular shape usually has certain advantages, such as the possibility of greater flexibility in space utilisation and easier adaptation to specific installation environments and piping layouts. Also, rectangular construction may be easier to manufacture and maintain than other shapes of heat exchangers.

In industry, rectangular air-to-air heat exchangers are also commonly used for air temperature regulation in various processes, helping to optimise production processes and reduce energy costs.

The operating principle of rectangular air-to-air heat exchangers is based on the principle of heat transfer.

The interior of the heat exchanger usually consists of a series of parallel partitions or fins that divide the heat exchanger into two separate air channels.

When two air streams of different temperatures flow through these two channels, heat is transferred from the warmer air to the cooler air through the partitions or fins.

For example, in winter, warmer indoor exhaust air passes through one channel, while cooler fresh outdoor air passes through the other. Since the partitions or fins have good thermal conductivity, the heat from the indoor air is transferred to the outdoor air, thus raising the temperature of the fresh air entering the room to some extent.

In summer, the opposite is true, with the cooler indoor exhaust air cooling the hotter outdoor fresh air.

This heat transfer process can be achieved by a combination of thermal conduction, convection and radiation. The material and structural design of the partitions or fins can affect the efficiency of heat transfer.

For example, the use of metal materials with good thermal conductivity for partitions, as well as increasing the surface area and optimising the shape of fins, can improve the effectiveness of heat exchange.

In addition, factors such as the air flow rate, temperature difference, and the size and structure of the heat exchanger will also have an impact on its working performance. Too fast a flow rate may lead to insufficient heat exchange time, while too slow a flow rate may affect ventilation. Larger temperature differences are usually favourable for more efficient heat exchange, but the tolerance of the equipment and the practical application needs to be taken into account.
