Do You Offer Customization Options for The Ripening Air Cooler?

we provide full OEM & ODM customization for all ripening air coolers tailored to banana, mango and other fruit pressurized ripening chambers. We adjust every parameter to match your chamber size, fruit type, refrigerant system and local operation standards.

1. Core Structural & Cooling Customization

• Cooling capacity: Custom design from 5kW to 60kW based on your ripening room volume, pallet loading tonnage and fruit respiration heat load

• Heat exchanger coil customization

  • Tube material: Copper tube, 304 / 316 stainless steel tube (for high-humidity ethylene corrosive environment)

  • Fin options: Standard aluminum, hydrophilic coated epoxy fins, anti-corrosion stainless steel fins

  • Fin spacing: 4.0/4.5/5.0mm wide fins (specially for ripening rooms to reduce frosting and airflow blockage)

  • Coil design: Low TD gentle cooling coil to maintain 85–95% RH and avoid fruit weight loss

• Refrigerant compatibility: Custom for CO₂ transcritical system, R404A, R449A, ammonia, glycol chilled water systems

2. Fan & Airflow Customization (Key for Even Temperature Distribution)

• Fan type: Standard AC axial fans, energy-saving EC variable speed fans, reversible dual-flow fans for symmetrical chamber circulation

• Static pressure customization: 150–400Pa high-static fans exclusively for pressurized ripening chambers to force air through mango/banana cartons and eliminate hot spots

• Fan quantity & layout: 2/3/4/6 fan units, single-side discharge or double-side horizontal airflow pattern

• Motor protection grade: IP54 / IP55 / IP65 optional for high-humidity food-grade workshop

3. Material & Housing Customization (Food Safety Focus)

• Outer casing & drain pan: Galvanized steel with anti-rust coating, full 304 stainless steel for strict food hygiene requirements

• Suspension brackets: Custom heavy-duty stainless steel hangers with shock absorption pads for ceiling mounting

• Drain system: Sloped stainless drain pan, heat tracing cable and U-shaped water trap optional to prevent drain freeze and odor backflow

4. Defrost System Customization

• Electric heating defrost (standard for small & medium ripening rooms)

• Hot gas defrost (custom for large continuous-operation ripening factories, energy-saving)

5. Electrical & Control Customization

• Voltage custom: 380V/415V 3-phase, match local power standards for Middle East, Southeast Asia, Europe and America

• Control box: Standalone waterproof control cabinet, or reserve signal interface to connect your central ripening PLC system (support linkage with ethylene generator, CO₂ scrubber, temperature & humidity sensors)

• Optional IoT remote monitoring module for real-time data check

6. Extra Custom Service

1. OEM: Print your brand logo on unit casing, custom export wooden packaging

2. Size tailor-made: Adjust unit length, width, height to fit limited ceiling space of your existing ripening chamber

3. Technical drawing support: Provide CAD installation drawing, airflow layout design for your project

4. Matching accessories: Custom air deflectors, air distribution plenum ducts as a complete set

Closing sales sentence

Just share your ripening room dimensions, fruit type, target temperature & humidity and refrigerant type, our engineering team will design a fully customized ripening air cooler solution with even temperature distribution and zero hot spots.
